Flatbed semi trailers are generally used for bulk carriers or ro-ro ships for transportation.
The flatbed trailer is a kind of trailer whose design is suitably made to carry bulk cargo and containers between shipping facilities and terminals.
| Flatbed Semi Trailer Specification | ||||
| √ Name: carbon steel flat bed Semi trailer | ||||
| √ Loading capacity: 50T | ||||
| √ Size:12500x2500x1600mm | ||||
| Top flange plate | Material and thickness | Q345B 14mm | ||
| Bottom flange plate | Material and thickness | Q345B 16mm | ||
| Material | Q345B | |||
| Middle flange plate | Thickness | 8mm | ||
| Chassis | Height | 500mm | ||
| (I beam) | Type | U steel | ||
| Side beam height | Bending parts | |||
| Height | 16# U steel | |||
| Material | Carbon steel Q235 | |||
| Floor | Thickness | 3mm | ||
| Floor type | Checkered plate | |||
| Container twist lock | 12pcs for 1x40ft and 2x20ft container | |||
| Axle | FUWA, 13T *3/2 | |||
| Rim | Type | 9.0-22.5 | ||
| Number | 12 pcs | |||
| Running mechanism | Brand | Taitong brand | ||
| Tire | Type | 12R22.5 | ||
| Number | 12pcs | |||
| Suspension | Mechanical suspension | |||
| Leaf width | 90mm | |||
| Spring leaf | Leaf thickness | 13mm | ||
| Layer/set | 10 Layer | |||
| King pin | Type | Bolts type | ||
| Diameter | 2 inch | |||
| Air tank | 40L air tanks | |||
| Running mechanism | Brake system | Brake chamber | 4double spring brake chamber | |
| ABS | Without | |||
| Landing gear | Brand | Zhongli brand | ||
| Type | 28T two speed | |||
| Spare tire carrier | 2sets | |||
| Light | LED light | |||
| Accessories | Voltage | 24v | ||
| Receptacle | 7 ways(7wire harness)and quick change type | |||
| Tool box | One piece,1000x500x500mm | |||
| Painting | Polyurethane paint&anti-rust primer&sand blasting | |||
| Tools | Head wrench ;spare wheel crank ; | |||
