Skeleton semi trailer, also called skeletal trailers, are lightweight semitrailers usually designed for transporting containers.
The skeletal semi trailer is a kind of container semi-trailer frame, which can only be used to transport containers. The skeleton semi trailer is welded by longitudinal beam, cross beam and front and rear end beams. The longitudinal beam is welded into I-shape by submerged arc welding of steel plate.
| Type: | 40ft Skeleton semi trailer | |
| Dimensions: | Outside dimension | 12400*2490*1400 mm |
| (The final dimensions depend on the final design drawings) | ||
| Design/welding technology | Heavy duty and extra durability designed; | |
| welding by automatic Submerged-Arc processes. | ||
| Frame: | ||
| Opting for high strength Q345B steel, | ||
| 500mm deep welded I-section main beams | ||
| Main beam | Top Flange thickness 14mm | |
| Bottom Flange thickness 16mm | ||
| Middle Flange thickness 8mm; | ||
| Axle | 2 *13 tons capacity, YORK brand | |
| King Pin | 2.00’’(50#) bolting king pin | |
| Suspension | Two-axle suspension with equalizers, American design | |
| Steel Spring | Four sets of 10pcs leaf spring | |
| Twist Locks | 8 units ISO twist locks | |
| Landing legs | 28 Tons manual operation landing legs with sand shoe | |
| OEM parts: | Tire specs | 11R22.5, Aeolus brand |
| Rim | 8.25-22.5 | |
| Number of wheel | 8 pieces | |
| Four double brake chamber; | ||
| Brake system | Two units of reliable local brand standard coppery air-connector. | |
| Electrical: | One unit of 24V 7-pin ISO socket; LED light | |
| Sand blasting before painting; | ||
| one coats of primer, anti-corrosion; | ||
| Painting | two coat of finish painting; | |
| Miscellaneous: | color advised by client | |
| Marking | Standard | |
| Side Guard | Standard | |
| Spare Tire Carriers | Standard | |
| Tools box | Standard | |
| Note: All the details not mentioned should comply with Chinese regulations. | ||
